CM-3000 CNC Hot Wire Cutting Machine
Get a Quick QuoteThe CM-3000 CNC Hot Wire Cutting Machine is a eps cutting machines manufactured by ChinaEps, featuring max cutting length of 3,000 mm and cutting width of 1,200 mm. CE & ISO 9001 certified. Designed for eps insulation sheet cutting, construction panel production, medium-scale eps processing.
The CM-3000 is a CNC hot wire cutting machine designed for medium-scale EPS block processing into insulation sheets and construction panels. It features 3,000mm cutting length, up to 30 adjustable Ni-Cr alloy wires, automatic block feeding, and consistent ±1mm cutting accuracy at 7 kW installed power. Suitable for EPS manufacturers producing insulation boards, construction panels, and custom packaging shapes.
Key Specifications
Why Choose This Machine
CNC programmable cutting paths
Adjustable wire spacing for various thicknesses
Ni-Cr alloy hot wire for clean cuts
Automatic block feeding and positioning
Digital wire temperature control
Batch cutting mode for high efficiency
Applications
This machine is widely used across multiple industries and production scenarios.
Technical Specifications
| Parameter | Value |
|---|---|
| Max Cutting Length | 3,000 mm |
| Cutting Width | 1,200 mm |
| Wire Speed | 0-3,000 mm/min adjustable |
| Wire Type | Hot wire (Ni-Cr alloy) |
| Installed Power | 7 kW |
| Cutting Accuracy | ±1 mm |
| Number of Wires | 1-30 adjustable |
| Machine Weight | 2,800 kg |
* Specifications are subject to change without notice. Contact us for the latest technical data.
Certifications & Compliance
Product Video
Ready to Build Your EPS/EPP Production Line?
Get a customized turnkey solution — competitive pricing, proven technology, and full after-sales support from our engineering team.
