SPQ-KP EPS Block Sheet Slicer - EPS machinery manufacturer China
SPQ-KP
CE

SPQ-KP EPS Block Sheet Slicer

Get EPS Machine Pricing — Reply in 4 Hours

SPQ-KP EPS Block Sheet Slicer — eps cutting lines by ChinaEps, CE certified.

The SPQ-KP is a dedicated horizontal-only sheet slicer for small EPS workshops — slices blocks into flat sheets without vertical or cross-cut capability, at roughly 40% lower price than the full SPQ-B continuous cutting line. Best fit for entry-level factories upgrading from manual hot-wire benches.

Key Specifications

Model
SPQ-KP EPS Block Sheet Slicer
Block Length (L)
2,000-4,000 mm
Block Width (W)
1,000-1,260 mm
Block Height (H)
500-1,000 mm
CE and ISO 9001 Certified 5-Year Warranty 24h Technical Response
Send Inquiry Download Specifications

Technical Specifications

Parameter Value
Model SPQ-KP EPS Block Sheet Slicer
Block Length (L) 2,000-4,000 mm
Block Width (W) 1,000-1,260 mm
Block Height (H) 500-1,000 mm
Slice Pitch 10-300 mm (variable per recipe)
Cutting Method Horizontal hot-wire bank only (no vertical/cross cuts)
Cutting Speed 1-3 m/min
Wire Count 20-40 horizontal wires
Voltage 380V / 50Hz
Heating Power 18 kW
Motor Power 5.5 kW
Machine Weight 2,800 kg

* Specifications are subject to change without notice. Contact us for the latest technical data.

What This Machine Solves

Three production problems eliminated by this machine — with engineered, measurable solutions.

The Problem

Small EPS workshops producing flat sheets don't need vertical/cross cuts but pay 40-50% premium for SPQ-B's extra features

How This Machine Solves It

SPQ-KP is horizontal-only sheet slicer — 40% lower CAPEX than SPQ-B with same horizontal cutting quality (±0.5 mm tolerance).

The Problem

Manual hot-wire benches produce inconsistent thickness — operators struggle to hold ±2mm tolerance let alone ±0.5

How This Machine Solves It

SPQ-KP's 20-40 wire automated bank holds ±0.5mm tolerance over the full block length — same spec as premium SPQ-B horizontal cutting.

The Problem

Entry-level factories overrun budget upgrading from manual to full SPQ-B — sticker shock kills the upgrade conversation

How This Machine Solves It

USD 22,000-28,000 sticker price is half of SPQ-B — still has PLC, automated wires, CE safety. Right step up from manual benches.

Working Principle

SPQ-KP runs blocks through a fixed horizontal wire bank. No vertical or cross cuts. Operator sets wire spacing per recipe, blocks travel through cutting zone at PLC-controlled 1-3 m/min, sheets discharge onto output conveyor.

Step 1

1. Block Loading

Manual or pneumatic loading of aged EPS block onto conveyor.

Step 2

2. Wire Setup

Operator positions 20-40 horizontal wires per recipe (10-12 min manual setup vs 1-3 min on SPQ-B robotic).

Step 3

3. Horizontal Slicing

Block travels through wire bank at 1-3 m/min; wires slice block into stacked sheets at ±0.5 mm tolerance.

Step 4

4. Sheet Discharge

Sliced sheets discharge stacked onto output conveyor; operator picks up bundles for storage.

Engineered Performance Advantages

Every advantage backed by measurable specs — no marketing claims without data.

Investment vs SPQ-B
40% lower
vs SPQ-B reference

Right CAPEX for sheet-only producers.

Horizontal Cut Quality
±0.5 mm
vs manual benches ±2 mm

Same automated tolerance as SPQ-B horizontal cutting.

Cutting Speed
1-3 m/min
vs SPQ-B 0.6-2 m/min

Faster on simple horizontal sheets due to no vertical/cross cut overhead.

Footprint
4 × 2 m
vs SPQ-B 6 × 1.1-2.4 m (U-type)

Compact installation for small workshops.

Wire Setup
10-12 min manual
vs SPQ-B 1-3 min robotic

Slower setup acceptable for sheet-only producers with stable SKU mix.

Real Production Applications

See where this machine fits in real factories.

Small EPS workshops producing flat sheets for local construction and packaging markets
Small EPS workshops producing flat sheets for local construction and packaging markets
Entry-level factories upgrading from manual hot-wire benches to automated sheet production
Entry-level factories upgrading from manual hot-wire benches to automated sheet production
Cold-chain box producers cutting flat foam sheets for box wall and lid panels
Cold-chain box producers cutting flat foam sheets for box wall and lid panels
Building material wholesale supply — standard sheet sizes for distribution
Building material wholesale supply — standard sheet sizes for distribution
Workshop-scale operations that cannot justify the full SPQ-B continuous cutting line
Workshop-scale operations that cannot justify the full SPQ-B continuous cutting line
Backup or secondary cutting line in larger factories for handling overflow sheet orders
Backup or secondary cutting line in larger factories for handling overflow sheet orders

Product FAQ

The questions buyers ask most often before placing an order.

Can SPQ-KP be upgraded later to add vertical/cross cuts?
No — different machine architecture. If you need vertical/cross cuts in the future, you'd add a separate SPQ-B line. Most SPQ-KP buyers stay sheet-only for years.
What's the minimum sheet thickness?
10 mm (matches SPQ-B minimum). For thinner slicing (5-8 mm specialty products), consider SPQ-B with finer wire setup.
Wire setup time really 10-12 minutes vs SPQ-B's 3 minutes?
Yes — manual setup is slower than robotic. The tradeoff is acceptable if you change recipes infrequently (e.g., one recipe per week or month). If you switch SKUs daily, SPQ-B's robotic setup pays for itself in setup time savings.
Can SPQ-KP cut graphite/FR-EPS?
Standard EPS only. For graphite/FR-EPS production at scale, use SPQ-FR.
Ships to 220V/60Hz?
Yes — factory build option. 2-week lead time adjustment.

Build a Complete EPS Line

This machine integrates into the full ChinaEps production flow — upstream, downstream, and auxiliary equipment from one supplier.

Upstream — Bead Preparation

SPB-WZ Block Molding

Right-sized block molder for SPQ-KP throughput. Standard 1.4 × 0.8 × 0.5 m blocks slice cleanly on SPQ-KP.

PE-1200 Pre-Expander

Standard EPS expansion sized for SPQ-KP scale workshops.

Downstream — Finishing & Packing

SPLB-1200 Film Packing

Shrink-wraps SPQ-KP sheet output into palletized bundles for distribution.

Auxiliary Systems

Upgrade Path to SPQ-B

When you need vertical/cross cuts (custom sheet widths and lengths), SPQ-B is the natural upgrade — SPQ-KP stays as secondary line.

Why ChinaEps — Factory Strength

Full in-house manufacturing capability behind every machine we ship.

20+
Years in EPS Machinery
12,000 m²
Manufacturing Floor
60+
Export Countries
500+
EPS Factories Equipped

Certifications & Compliance

CE
Internationally Certified

Service Commitment

Beyond shipping — we stand behind every machine we deliver.

5-Year Warranty

Core components warranted for 5 years; standard parts 12 months.

24h Remote Response

Technical engineers respond within 24 hours via WhatsApp / email / video call.

Global On-Site Service

Our technicians travel worldwide for installation, commissioning, and repair.

Operator Training

Hands-on training plus full technical documentation in your language.

ROI Snapshot

Quick reference numbers — for a precise quote with your factory data, use the ROI Calculator.

Equipment Investment
USD 22,000-28,000 (FOB Shanghai)
Payback Period
10-14 months at 8-15 t/day flat sheet output
Throughput
12-25 t/day single-shift, 24-50 t/day double-shift
Run Detailed ROI Calculator →
